4.5” x 20” Commercial/Industrial Stainless Steel Single Cartridge Filter Housing
The US Water Systems SS Filter Housings are made of 304 stainless and accept any double open-end (DOE) cartridge. These housings are designed for high-temperature (up to 200°F) and high- pressure (up to 300 psi). The spring-loaded knife seal edge provides a positive seal for 19.5” or 20” cartridges.
Features and Benefits
- Ring-Nut Closure – Provides easy filter change with a positive seal.
- All Stainless Steel – Ideal for a variety High Purity commercial and industrial applications
- 1” Inlet and Outlet – Flows up to 22 GPM
- Includes Mounting Bracket and Screws – For easy installation
- Uses DOE Cartridges – Readily available
- Meets FDA Requirements – Safe for all potable water, food and beverage applications
Applications
- Chemicals
- Electronics
- Wastewater
- Potable Water
- Food & Beverage
- RO Pre-filtration
- Plating Solutions
- Coolants & Inks
- Paints & Coatings
- Photographic Solutions
Specifications
- Inlet/Outlet: 1”
- Drain (on bottom): 1/4”
- Body: 304 Stainless Steel
- Head: 304 Stainless Stel
- O-Ring: EPDM
- Maximum Working Pressure: 300 psi (20.68 bar)
- Maximum Operating Temperature: 200°F (93°C)
