| Product Details | |
|---|---|
|
Application |
Water Food Beverage |
|
Body Material |
Acetal Copolymer |
|
Inlet Connection |
1/4″ Compression |
|
Max Pressure (Psi) |
120 |
|
Max Temp (°F) |
180 |
|
Min Pressure (Psi) |
vacuum |
|
Min Temp (°F) |
-40 |
|
Mounting Options |
Free Floating |
|
Nsf Version |
Yes |
|
Number Of Seals |
2 |
|
Outlet Connection |
1/4″ Compression |
|
Seal Material |
FDA EPDM |
|
Series |
APC |
|
Shape |
Straight |
|
Size |
1/4″ |
|
Spring |
316 Stainless Steel |
|
Valve Type |
Valved |
|
Color / Finish |
White Natural |
|
Connection Type |
Compression |
|
Type |
Coupling Insert |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 42 |
