NOTE:The Everpure H-300 HSD (HSD=High Silt Density) is made specifically to filter out silt. Most customers do not require this additional feature and should order the Everpure H-300 filter system.
To ensure the highest quality drinking water, filter cartridge replacements are recommended at least once annually, when flow is diminished, or when the system’s rated capacity is reached. Replace your cartridge with the Everpure EV9270-75.
Consumer Note & Included Components Chart:
Consumer Note:To ensure you get the best value, our water specialists here at Fresh Water Systems created the EVRQDIY-300-HSD water filtration system as a cheaper alternative to the Everpure EV9270-77 system. We recommend the EVRQDIY-300-HSD, as it is backed by our specialists to provide you with safer drinking water at a lower price.
Please note that Fresh Water Systems has upgraded one of the fixed elbow fittings originally included with the QL3 head kit to a swivel elbow. This swivel allows more flexibility during installation and an easier install process. During installation, the male stem adapter is installed first to the inlet side of the head. Once the stem is tightened, a quick-connect elbow is installed to the stem and completes the swivel.
| System Components | EVRQDIY-300-HSD |
| QL3 Filter Head |
✔ |
| H-300-HSD Filter Cartridge |
✔ |
| Fittings Kit |
✔ |
| 1/4″ OD Tubing |
✔ |
| Teflon Tape |
✔ |
| Filter Timer |
Sold Separately. |
| Faucet |
Sold Separately |
| Product Details | |
|---|---|
|
Application |
Drinking Water |
|
Capacity |
300 Gallons |
|
Max Pressure (Psi) |
125 |
|
Max Temp (°F) |
100 |
|
Micron Rating (Nominal) |
0.5 µm |
|
Min Pressure (Psi) |
10 |
|
Min Temp (°F) |
35 |
|
Push-In Size |
1/4″ OD |
|
Change Frequency |
300 Gallons |
|
Contaminants Reduced |
Bacteria Chlorine/Taste/Odor Chloramine Sediment/Dirt/Rust Cysts Heavy Metals Lead Mold & Algae Scale VOCs |
|
Flow Rate |
0.5 GPM |
|
Type |
Under-Sink System |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 42 |
| Shipping Dimensions | |
|
Shipping Length |
20 in. |
|
Shipping Width |
8 in. |
|
Shipping Height |
4 in. |
| Product Weight & Dimensions | |
|
Approx Depth |
5″ |
|
Product Height |
22″ |
|
Product Width |
5″ |
|
Product Weight (lbs) |
4.2 |
