The John Guest For connecting OD tubing through a cabinet wall or bulkhead. Makes installations quick and easy. JG Push-fit technology makes connecting tubing quick and easy. Fittings are manufactured in gray acetal with food grade nitrile O-ring, making them especially suitable for applications involving foodstuffs and potable liquids. They are also suitable for air and inert gases therefore can be used for CO2 and nitrogen beverage gas lines, pneumatics, vacuum as well as other applications.
Features & Benefits:
Working Pressure & Temperature
| Product Details | |
|---|---|
|
Application |
Water Air Food Beverage |
|
Body Material |
Acetal Copolymer |
|
Max Pressure (Psi) |
230 |
|
Max Temp (°F) |
150 |
|
Min Pressure (Psi) |
Vacuum |
|
Min Temp (°F) |
-4 |
|
Mounting Options |
Panel Mount |
|
Push-In Size |
1/2″ OD 1/4″ OD |
|
Seal Material |
Buna-N |
|
Series |
PI |
|
Shape |
Straight |
|
Color / Finish |
Gray |
|
Sub-Type |
Reducer Bulkhead |
|
Type |
Bulkhead |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61, NSF/ANSI 51 |
