The John Guest brass male coupler makes connecting Copper, PEX, or CPVC to female NPT threads easy. Push-fit connection securely grips pipe. Fast and easy to use – no soldering, glue or clamps. Approved for behind-the-wall applications and can be used for permanent installations. Ideal for work in tight spaces. Can be disconnected without damage to tubing.
Features:
Working pressure and temperature:
| Product Details | |
|---|---|
|
Application |
Water Food Beverage |
|
Body Material |
Brass |
|
Inlet Connection |
3/4″ MPT |
|
Max Pressure (Psi) |
174 |
|
Max Temp (°F) |
221 |
|
Min Pressure (Psi) |
0 |
|
Min Temp (°F) |
-4 |
|
Mounting Options |
Thread |
|
Outlet Connection |
3/4″ MPT |
|
Push-In Size |
7/8″ OD |
|
Seal Material |
EPDM |
|
Series |
Brass |
|
Shape |
Straight |
|
Size |
3/4″ |
|
Color / Finish |
Brass |
|
Connection Type |
Male (MPT) |
|
Origin |
United Kingdom |
|
Size Type |
Common Tube Size (CTS) |
|
Sub-Type |
Male Adapter |
|
Type |
Adapter |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61 |
