Working Pressure & Temperature:
About ProLock: The John Guest ProLock series has been designed with an audible click and visible alignment arrows to assure installers that a fitting is secure. Fittings are ideal for use in water softener/conditioner systems and virtually any OEM type of application involving joining solutions.
ProLock fittings have a collet with stainless steel teeth that grip the pipe when fully inserted, and an O-ring to provide a permanent, leakproof seal. When twisted into place, the locking cap locks the pipe in place securely. No special tools, soldering, clamps or glue are ever required. Fittings reduce installation times by more than 40% and are code-approved for behind-the-wall use.
| Application | Max Working Pressure | Max Working Temperature |
|
Water
Water
Water
|
160 PSI
100 PSI
80 PSI
|
73° F
180° F
200° F
|
| Product Details | |
|---|---|
|
Application |
CPVC Copper Tubing Material PEX |
|
Body Material |
Polysulfone |
|
Inlet Connection |
3/4″ NPS |
|
Max Pressure (Psi) |
160 |
|
Max Temp (°F) |
200 |
|
Min Pressure (Psi) |
0 |
|
Min Temp (°F) |
33 |
|
Mounting Options |
Thread |
|
Nut / Fitting Material |
Polysulfone |
|
Outlet Connection |
3/4″ NPS |
|
Push-In Size |
5/8″ OD |
|
Seal Material |
EPDM |
|
Series |
ProLock |
|
Shape |
Straight |
|
Size |
3/4″ |
|
Color / Finish |
Black |
|
Connection Type |
NPS |
|
Origin |
UK |
|
Size Type |
Common Tube Size (CTS) |
|
Sub-Type |
Female Adapter |
|
Type |
Adapter |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61 |
|
Warranty |
25 Years |
