John Guest Reducing Tee – 1 x 1 x 3/4 CTS

🚚 Free Shipping over $39

✓ Premium Quality

🔒 Secure Payments

↻ Money Back Guarantee

SKU: PEI3036A

CATEGORY: Fittings & Connectors

Description

The John Guest Speedfit reducing tee makes joining copper, PEX or CPVC in any combination quick and easy. Incorporates Twist-to-Lock for added security. Approved for behind-the-wall applications and can be used for permanent installations. These are ideal for work in tight spaces. Fittings can be disconnected without damage to tubing.

Features:

Twist-to-Lock Technology creates reliable, leak-free connections
Compatible with copper, PEX and CPVC in any combination
No tools, soldering, glue or clamps required for installation
Can be installed on wet lines (hot and cold water)
Approved for behind-the-wall applications with no access panel
Can be disconnected as needed
EPDM O-Rings
Manufactured in high-quality engineered plastic
Made with lead free materials

Working pressure and temperature:

160 psi at 73° F
100 psi at 180° F
80 psi at 200° F

Note: Not suitable for compressed air and vacuum applications

Specifications

Product Details
Application	CPVC Copper Tubing Material PEX
Body Material	Polypropylene
Max Pressure (Psi)	160
Max Temp (°F)	200
Min Pressure (Psi)	0
Min Temp (°F)	33
Mounting Options	Free Floating
Push-In Size	1-1/8″ OD 7/8″ OD
Seal Material	EPDM
Series	PEI
Shape	Tee
Color / Finish	White
Origin	United Kingdom
Size Type	Common Tube Size (CTS)
Sub-Type	Reducer Tee
Type	Tee
Warranty & Certifications
Warranty	25 Years

Product Details
Application	CPVC Copper Tubing Material PEX
Body Material	Polypropylene
Max Pressure (Psi)	160
Max Temp (°F)	200
Min Pressure (Psi)	0
Min Temp (°F)	33
Mounting Options	Free Floating
Push-In Size	1-1/8″ OD 7/8″ OD
Seal Material	EPDM
Series	PEI
Shape	Tee
Color / Finish	White
Origin	United Kingdom
Size Type	Common Tube Size (CTS)
Sub-Type	Reducer Tee
Type	Tee
Warranty & Certifications
Warranty	25 Years
