Applications:
| Kynar w/Viton Seal |
Tube O.D. |
NPTF |
M | N | D |
| F4ME2 | 1/4 |
1/8 |
0.84 |
0.94 |
.175 |
| F4ME4 | 1/4 |
1/4 |
0.84 |
0.94 |
.175 |
| F4ME6 | 1/4 |
3/8 |
0.84 |
1.04 |
.175 |
| F6ME4 | 3/8 |
1/4 |
1.03 |
1.08 |
.250 |
| F6ME6 | 3/8 |
3/8 |
1.03 |
1.08 |
.250 |
| F6ME6 | 3/8 |
3/8 |
1.03 |
1.06 |
.250 |
| Product Details | |
|---|---|
|
Application |
Water Air Beverage Beer Wine Soft Drinks Dyes |
|
Body Material |
Kynar |
|
Inlet Connection |
3/8″ MPT |
|
Max Pressure (Psi) |
250 |
|
Max Temp (°F) |
275 |
|
Min Pressure (Psi) |
Vacuum |
|
Min Temp (°F) |
0 |
|
Mounting Options |
Thread |
|
Outlet Connection |
3/8″ MPT |
|
Push-In Size |
1/4″ OD |
|
Seal Material |
FKM (Viton) |
|
Series |
TrueSeal |
|
Shape |
90 |
|
Size |
3/8″ |
|
Color / Finish |
White |
|
Connection Type |
Male (MPT) |
|
Origin |
U.S.A. |
|
Sub-Type |
Male Elbow |
|
Type |
Elbow |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 51 |
