| Product Details | |
|---|---|
|
Application |
Water |
|
Barb Size |
1/4″ ID |
|
Body Material |
Chrome-Plated Brass |
|
External Springs And Pin |
Stainless Steel |
|
Max Pressure (Psi) |
250 |
|
Max Temp (°F) |
180 |
|
Min Pressure (Psi) |
Vacuum |
|
Min Temp (°F) |
-40 |
|
Mounting Options |
Panel Mount |
|
Nsf Version |
No |
|
Seal Material |
Buna-N |
|
Series |
LC |
|
Shape |
Straight |
|
Spring |
316 Stainless Steel |
|
Thumb Latch |
Stainless Steel |
|
Valve Type |
Valved |
|
Color / Finish |
Chrome |
|
Origin |
U.S.A. |
|
Type |
Coupling Insert |
