Applications:
Compatible with the American Filtration 820-5B and Watts FMPIC-90-5-HT.
Compatible with:
| American Filtration Technologies | 820-5B |
| Watts | FMPIC-90-5-HT |
| Product Details | |
|---|---|
|
Gaskets |
Buna-N |
|
Max Pressure (Psi) |
75 |
|
Max Temp (°F) |
250 |
|
Micron Rating (Nominal) |
5 µm |
|
Surface Area |
Approximately 90 Square Feet |
|
Cap Material |
Electro Plated Tin |
|
Cartridge Style |
Drop-in |
|
Diameter |
7-5/8″ |
|
Media Type |
Phenolic Impregnated Cellulose |
|
Origin |
U.S.A. |
| Shipping Dimensions | |
|
Shipping Length |
20 in. |
|
Shipping Width |
8 in. |
|
Shipping Height |
8 in. |
| Product Weight & Dimensions | |
|
Product Length |
19 1/2″ (49.5 cm) |
|
Product Weight (lbs) |
6.375 |
| Product Details | |
|---|---|
|
Gaskets |
Buna-N |
|
Max Pressure (Psi) |
75 |
|
Max Temp (°F) |
250 |
|
Micron Rating (Nominal) |
5 µm |
|
Surface Area |
Approximately 90 Square Feet |
|
Cap Material |
Electro Plated Tin |
|
Cartridge Style |
Drop-in |
|
Diameter |
7-5/8″ |
|
Media Type |
Phenolic Impregnated Cellulose |
|
Origin |
U.S.A. |
| Product Weight & Dimensions | |
|
Product Weight (lbs) |
48 |
