NeoFit – Acetal Black Female Adapter 8mm(5/16″) tube x 1/2″ BSP(P) – Cone Type

🚚 Free Shipping over $39

✓ Premium Quality

🔒 Secure Payments

↻ Money Back Guarantee

SKU: AFAC8M-G4-E

CATEGORY: Tubing & Hose

Description

The female connector makes connecting tubing to male threads quick and easy. Manufactured in acetal copolymer with food grade EPDM O-ring, these fittings are suitable for pure water, potable liquids, air & gas.

Features:

Used to connect OD tubing sizes to male threads
Compatible with plastic or copper OD sized tubing
Food Quality and suitable for potable liquids and pure water applications
Also suitable for air & gas
Acetal body with food grade EDPM O-Ring

Specifications

Product Details
Material	Acetal
Max Pressure (Psi)	Max. 170 psi at 68° F Max. 100 psi at 150° F
Push-In Size	5/16″ OD
Color / Finish	Black
Sub-Type	Female Adapter
Type	Adapter
Warranty & Certifications
Product Certification Standard	NSF/ANSI 51

Product Details
Material	Acetal
Max Pressure (Psi)	Max. 170 psi at 68° F Max. 100 psi at 150° F
Push-In Size	5/16″ OD
Color / Finish	Black
Sub-Type	Female Adapter
Type	Adapter
Warranty & Certifications
Product Certification Standard	NSF/ANSI 51

Product Details
Material	Acetal
Max Pressure (Psi)	Max. 170 psi at 68° F Max. 100 psi at 150° F
Push-In Size	5/16″ OD
Color / Finish	Black
Sub-Type	Female Adapter
Type	Adapter
Warranty & Certifications
Product Certification Standard	NSF/ANSI 51

Product Information

SKUAFAC8M-G4-E
CategoryTubing & Hose

NeoFit – Acetal Black Female Adapter 8mm(5/16″) tube x 1/2″ BSP(P) – Cone Type
