Note: For reference purposes, please note that part number AFA5-NH6-G is equivalent to AFA8M-NH6-G
The NeoFit female adapters are used to connect OD tubing sizes to male threads. Manufactured in acetal with food grade EPDM O-ring, these fittings were design for water, beverage, and food applications. They are also suitable for air and inert gases therefore can be used for CO2 and nitrogen beverage gas lines, pneumatics, vacuum as well as other applications.
Features:
|
Size |
NEO: Working PSI @ Temp |
JG: Working PSI @ Temp |
DM Fit: Working PSI @ Temp |
|---|---|---|---|
|
1/4″ |
290psi @ 68F/ 232psi @ 150F |
230psi @ 68F/ 150 psi at 150F |
230psi @ 68F/ 100 psi at 150F |
|
3/8″ |
232psi @ 68F/ 203psi @ 150F |
150psi @ 68F/ 100 psi at 150F |
170psi @ 68F/ 100 psi at 150F |
|
1/2″ |
203psi @ 68F/ 116psi @ 150F |
150psi @ 68F/ 100 psi at 150F |
170psi @ 68F/ 100 psi at 150F |
|
Certifications |
NEO: NSF 51 & 61 Certified |
JG: NSF 51 & 61 Certified |
DM Fit: NSF 51 & 61 Certified |
|
Size |
NEO: Max Torque |
JG: Max Torque |
DM Fit: Max Torque |
|---|---|---|---|
|
1/4″ |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
|
3/8″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
|
1/2″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
| Product Details | |
|---|---|
|
Body Material |
Acetal Copolymer |
|
Max Pressure (Psi) |
Max. 170 psi at 33° F Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Push-In Size |
5/16″ OD |
|
Color / Finish |
Gray |
|
Sub-Type |
Female Adapter |
|
Type |
Adapter |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61, NSF/ANSI 51 |
| Product Details | |
|---|---|
|
Body Material |
Acetal Copolymer |
|
Max Pressure (Psi) |
Max. 170 psi at 33° F Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Push-In Size |
5/16″ OD |
|
Color / Finish |
Gray |
|
Sub-Type |
Female Adapter |
|
Type |
Adapter |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61, NSF/ANSI 51 |
| Product Details | |
|---|---|
|
Body Material |
Acetal Copolymer |
|
Max Pressure (Psi) |
Max. 170 psi at 33° F Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Push-In Size |
5/16″ OD |
|
Color / Finish |
Gray |
|
Sub-Type |
Female Adapter |
|
Type |
Adapter |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 61, NSF/ANSI 51 |
