The check valve allows fluid to flow one way and prevents reverse flow. Manufactured in acetal copolymer with food grade EPDM O-ring, these fittings are suitable for pure water, potable liquids and other beverage applications.
Features:
|
Size |
NEO: Working PSI @ Temp |
JG: Working PSI @ Temp |
DM Fit: Working PSI @ Temp |
|---|---|---|---|
|
1/4″ |
290psi @ 68F/ 232psi @ 150F |
230psi @ 68F/ 150 psi at 150F |
230psi @ 68F/ 100 psi at 150F |
|
3/8″ |
232psi @ 68F/ 203psi @ 150F |
150psi @ 68F/ 100 psi at 150F |
170psi @ 68F/ 100 psi at 150F |
|
1/2″ |
203psi @ 68F/ 116psi @ 150F |
150psi @ 68F/ 100 psi at 150F |
170psi @ 68F/ 100 psi at 150F |
|
Certifications |
NEO: NSF 51 & 61 Certified |
JG: NSF 51 & 61 Certified |
DM Fit: NSF 51 & 61 Certified |
|
Size |
NEO: Max Torque |
JG: Max Torque |
DM Fit: Max Torque |
|---|---|---|---|
|
1/4″ |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
1ft/lb (1.5nm) |
|
3/8″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
|
1/2″ |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
2ft/lb (3 nm) |
| Product Details | |
|---|---|
|
Application |
Water Air Food Beverage |
|
Body Material |
Acetal |
|
Max Pressure (Psi) |
Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Min Temp (°F) |
-4 |
|
Push-In Size |
8mm OD |
|
Seal Material |
Buna-N |
|
Color / Finish |
Gray |
|
Origin |
Korea |
|
Type |
Check Valve |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 51 |
| Shipping Dimensions | |
|
Shipping Length |
0.692 in. |
|
Shipping Width |
0.692 in. |
|
Shipping Height |
1.503 in. |
| Product Weight & Dimensions | |
|
Product Height |
1.503 in. |
|
Product Length |
0.692 in. |
|
Product Width |
0.692 in. |
|
Product Weight (lbs) |
0.0625 |
| Product Details | |
|---|---|
|
Application |
Water Air Food Beverage |
|
Body Material |
Acetal |
|
Max Pressure (Psi) |
Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Min Temp (°F) |
-4 |
|
Push-In Size |
8mm OD |
|
Seal Material |
Buna-N |
|
Color / Finish |
Gray |
|
Origin |
Korea |
|
Type |
Check Valve |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 51 |
| Product Weight & Dimensions | |
|
Product Weight (lbs) |
0.375 |
| Product Details | |
|---|---|
|
Application |
Water Air Food Beverage |
|
Body Material |
Acetal |
|
Max Pressure (Psi) |
Max. 170 psi at 68° F Max. 100 psi at 150° F |
|
Min Temp (°F) |
-4 |
|
Push-In Size |
8mm OD |
|
Seal Material |
Buna-N |
|
Color / Finish |
Gray |
|
Origin |
Korea |
|
Type |
Check Valve |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 51 |
| Product Weight & Dimensions | |
|
Product Weight (lbs) |
12.5 |
