Omnipure Inline K5605-JJ 5 mic Sediment Prefilter – 12″ x 2.5″ Filter – 1/4″ Quick Connect

🚚 Free Shipping over $39

✓ Premium Quality

🔒 Secure Payments

↻ Money Back Guarantee

SKU: K5605-JJ

CATEGORY: Fittings & Connectors

Description

The Omnipure K-Series K5605-JJ is a 5µm sediment filter and is best used as a system component. The K-Series from Omnipure is completely adaptable to various lengths and diameters to meet specific filtration needs. The versatility of the K5605-JJ can be used in ice makers, refrigerators, beverage equipment and drinking fountains.Reverse Osmosis systems can work together with purification systems to provide the purest water possible.
Specifications:

Rated Capacity: N/A (depends on the quality of water)
Service Flow Rate: 0.75 GPM (2.8 LPM)
Sediment Reduction: 5 microns
Maximum Pressure: 125 PSIG
Temperature: 35-100° F (2-38° C)
Polypropylene depth filtration
Protects downline equipment

Compatible with:

Vertex

IFA-4035

Specifications

Product Details
Max Pressure (Psi)	125
Max Temp (°F)	100
Micron Rating (Nominal)	5 µm
Min Temp (°F)	35
Cartridge Style	Inline
Change Frequency	6-12 Months
Connection Type	1/4″ Quick Connect
Contaminants Reduced	Sediment/Dirt/Rust
Diameter	2-1/2″
Filter Type	Inline
Flow Rate	0.50 GPM
Media Type	Coconut Shell Carbon Block
Micron Rating	5 µm
Warranty & Certifications
Product Certification Standard	NSF/ANSI 42
Shipping Dimensions
Shipping Length	4 in.
Shipping Width	4 in.
Shipping Height	18 in.
Product Weight & Dimensions
Product Height	2.75
Product Length	12.25
Product Width	2.75
Product Weight (lbs)	1.35

Product Details
Max Pressure (Psi)	125
Max Temp (°F)	100
Micron Rating (Nominal)	5 µm
Min Temp (°F)	35
Cartridge Style	Inline
Change Frequency	6-12 Months
Connection Type	1/4″ Quick Connect
Contaminants Reduced	Sediment/Dirt/Rust
Diameter	2-1/2″
Filter Type	Inline
Flow Rate	0.50 GPM
Media Type	Coconut Shell Carbon Block
Micron Rating	5 µm
Warranty & Certifications
Product Certification Standard	NSF/ANSI 42
Shipping Dimensions
Shipping Length	13 in.
Shipping Width	13 in.
Shipping Height	13 in.
Product Weight & Dimensions
Product Height	13
Product Length	13
Product Width	13
Product Weight (lbs)	33.75

Product Details
Max Pressure (Psi)	125
Max Temp (°F)	100
Micron Rating (Nominal)	5 µm
Min Temp (°F)	35
Cartridge Style	Inline
Change Frequency	6-12 Months
Connection Type	1/4″ Quick Connect
Contaminants Reduced	Sediment/Dirt/Rust
Diameter	2-1/2″
Filter Type	Inline
Flow Rate	0.50 GPM
Media Type	Coconut Shell Carbon Block
Micron Rating	5 µm
Warranty & Certifications
Product Certification Standard	NSF/ANSI 42
Shipping Dimensions
Shipping Length	13 in.
Shipping Width	13 in.
Shipping Height	24 in.
Product Weight & Dimensions
Product Length	13″
Product Weight (lbs)	67.5

Product Details
Max Pressure (Psi)	125
Max Temp (°F)	100
Micron Rating (Nominal)	5 µm
Min Temp (°F)	35
Cartridge Style	Inline
Change Frequency	6-12 Months
Connection Type	1/4″ Quick Connect
Contaminants Reduced	Sediment/Dirt/Rust
Diameter	2-1/2″
Filter Type	Inline
Flow Rate	0.50 GPM
Media Type	Coconut Shell Carbon Block
Micron Rating	5 µm
Warranty & Certifications
Product Certification Standard	NSF/ANSI 42
Shipping Dimensions
Shipping Length	13 in.
Shipping Width	24 in.
Shipping Height	24 in.
Product Weight & Dimensions
Product Length	13″
Product Weight (lbs)	135

Product Information

SKUK5605-JJ
CategoryFittings & Connectors

Omnipure Inline K5605-JJ 5 mic Sediment Prefilter – 12″ x 2.5″ Filter – 1/4″ Quick Connect
