NOTE: These cartridges are protected by Endurawrap, a uniquely formulated polyolefin bilaminate pre-filter, designed to significantly increase the useful life of the cartridge.
| Product Details | |
|---|---|
|
Capacity |
30,000 Gallons |
|
Cto Reduction Capacity |
30000 Gallons |
|
Gaskets |
Buna-N |
|
Initial Pressure Drop |
4 PSI Differential |
|
Inner/Outer Wraps |
Polyolefin |
|
Max Temp (°F) |
180 °F |
|
Micron Rating (Nominal) |
10 µm |
|
Min Temp (°F) |
40 °F |
|
Netting |
Polyethylene |
|
Cap Material |
Polypropylene |
|
Cartridge Style |
Drop-in |
|
Change Frequency |
6-12 Months |
|
Contaminants Reduced |
Sediment/Dirt/Rust Chlorine/Taste/Odor |
|
Diameter |
4-5/8″ |
|
End Cap Type |
Double Open Ended (DOE) |
|
Filter Type |
Carbon Block |
|
Flow Rate |
4 GPM |
|
Media Type |
Bonded Powdered Activated Carbon (PAC) |
|
Micron Rating |
10 µm |
|
Origin |
Assembled in the USA |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 42 |
| Shipping Dimensions | |
|
Shipping Length |
26 in. |
|
Shipping Width |
6 in. |
|
Shipping Height |
6 in. |
| Product Weight & Dimensions | |
|
Product Height |
4.5 |
|
Product Length |
20 |
|
Product Width |
4.5 |
|
Product Weight (lbs) |
7 |
| Product Details | |
|---|---|
|
Capacity |
30,000 Gallons |
|
Cto Reduction Capacity |
30000 Gallons |
|
Gaskets |
Buna-N |
|
Initial Pressure Drop |
4 PSI Differential |
|
Inner/Outer Wraps |
Polyolefin |
|
Max Temp (°F) |
180 °F |
|
Micron Rating (Nominal) |
10 µm |
|
Min Temp (°F) |
40 °F |
|
Netting |
Polyethylene |
|
Cap Material |
Polypropylene |
|
Cartridge Style |
Drop-in |
|
Change Frequency |
6-12 Months |
|
Contaminants Reduced |
Sediment/Dirt/Rust Chlorine/Taste/Odor |
|
Diameter |
4-5/8″ |
|
End Cap Type |
Double Open Ended (DOE) |
|
Filter Type |
Carbon Block |
|
Flow Rate |
4 GPM |
|
Media Type |
Bonded Powdered Activated Carbon (PAC) |
|
Micron Rating |
10 µm |
|
Origin |
Assembled in the USA |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 42 |
| Shipping Dimensions | |
|
Shipping Length |
22 in. |
|
Shipping Width |
10.5 in. |
|
Shipping Height |
10.25 in. |
| Product Weight & Dimensions | |
|
Product Height |
10.25 |
|
Product Length |
22 |
|
Product Width |
10.5 |
|
Product Weight (lbs) |
28 |
