| Product Details | |
|---|---|
|
Body Material |
Stainless Steel |
|
Capacity |
115-330 GPH |
|
Direction |
Clockwise |
|
Elastomer Type |
Buna-N |
|
Inlet Connection |
1/2″ MPT |
|
Mounting Options |
Clamp On |
|
Outlet Connection |
1/2″ MPT |
|
Power |
1 hp 2 hp |
|
Pump Max Flow Rate (Gpm) |
190 |
|
Series |
5 |
|
Size |
1/2″ |
|
Change Frequency |
115-330 GPH |
|
Connection Type |
Male (MPT) |
|
Type |
Rotary Vane Pumps |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 169 |
| Shipping Dimensions | |
|
Shipping Length |
6 in. |
|
Shipping Width |
6 in. |
|
Shipping Height |
4 in. |
| Product Weight & Dimensions | |
|
Dimensions |
Standard Clearance |
|
Product Height |
4 |
|
Product Length |
4.75 |
|
Product Width |
4 |
|
Product Weight (lbs) |
4.5 |
| Product Details | |
|---|---|
|
Body Material |
Stainless Steel |
|
Capacity |
115-330 GPH |
|
Direction |
Clockwise |
|
Elastomer Type |
Buna-N |
|
Inlet Connection |
1/2″ MPT |
|
Mounting Options |
Clamp On |
|
Outlet Connection |
1/2″ MPT |
|
Power |
1 hp 2 hp |
|
Pump Max Flow Rate (Gpm) |
190 |
|
Series |
5 |
|
Size |
1/2″ |
|
Change Frequency |
115-330 GPH |
|
Connection Type |
Male (MPT) |
|
Type |
Rotary Vane Pumps |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 169 |
| Shipping Dimensions | |
|
Shipping Length |
13.5 in. |
|
Shipping Width |
9 in. |
|
Shipping Height |
5.75 in. |
| Product Weight & Dimensions | |
|
Dimensions |
Standard Clearance |
|
Product Height |
5.75 |
|
Product Length |
13.5 |
|
Product Width |
5.75 |
|
Product Weight (lbs) |
24.408 |
| Product Details | |
|---|---|
|
Body Material |
Stainless Steel |
|
Capacity |
115-330 GPH |
|
Direction |
Clockwise |
|
Elastomer Type |
Buna-N |
|
Inlet Connection |
1/2″ MPT |
|
Mounting Options |
Clamp On |
|
Outlet Connection |
1/2″ MPT |
|
Power |
1 hp 2 hp |
|
Pump Max Flow Rate (Gpm) |
190 |
|
Series |
5 |
|
Size |
1/2″ |
|
Change Frequency |
115-330 GPH |
|
Connection Type |
Male (MPT) |
|
Type |
Rotary Vane Pumps |
| Warranty & Certifications | |
|
Product Certification Standard |
NSF/ANSI 169 |
| Shipping Dimensions | |
|
Shipping Length |
13 in. |
|
Shipping Width |
10 in. |
|
Shipping Height |
8 in. |
| Product Weight & Dimensions | |
|
Dimensions |
Standard Clearance |
|
Product Weight (lbs) |
40.5 |
