This is a standard-size reverse osmosis membrane filter housing with built-in 1/4″ quick-connect fittings.
Standard residential membranes made by Filmtec, GE, CSM, Pentair and many others ranging from 18 to 100 gallons per day, will fit in this housing.
If you are replacing a membrane housing that has threaded fittings, you may need to replace your check valve. Many housings with threaded fittings have the check valve built-in to the threaded fitting in the center port on the end with two ports.
Our CV-10 push-in check valve is ideal for use with HM-QC. A check valve is required for the proper functioning of an under-sink reverse osmosis system that uses a bladder tank.
| A: 1.50″ | B: 11.75″ | C: 10.00″ | D: 0.875″ | E: 0.678″ |
| Weight | 2 lbs |
|---|---|
| Fitting Size |
1/4″ |
