Additional Specifications:
Compatible with:
| CSM Membranes | RE4040 SHA, RE4040 SHF |
| Filmtec Membranes | SW30-4040 |
| Hydranautics Membranes | SWC5-4040, SWC5-LD-4040 |
| Koch Membrane Systems | TFC 4040 SW, TFC 4040 HF |
| Product Details | |
|---|---|
|
Active Area |
87 sq. ft. |
|
Average Nacl Rejection |
0.99 |
|
Cleaning Ph Range |
1-12 |
|
Direction |
Outside – In |
|
Feed Water Temperature |
77°F |
|
Inlet Pressure |
800 PSI |
|
Material Of Construction |
Cross-Linked Polyamide |
|
Max Feed Silt Density Index |
5 Silt Density Index |
|
Max Pressure Drop |
20 PSI Differential |
|
Max Pressure (Psi) |
1200 psi |
|
Max Temp (°F) |
113°F |
|
Membrane Type |
Spiral Wound |
|
Minimum Salt Rejection Cl- (%) |
0.995 |
|
Permeate Flow Rate |
1,900gpd (7.2) |
|
Permeate Tube Diameter |
3/4″ |
|
Ph Range |
2-11 |
|
Recovery Rate |
0.08 |
|
Diameter |
4″ |
|
Origin |
U.S.A. |
| Shipping Dimensions | |
|
Shipping Length |
43 in. |
|
Shipping Width |
5.75 in. |
|
Shipping Height |
5.75 in. |
| Product Weight & Dimensions | |
|
Product Height |
5.75 in. |
|
Product Length |
43 in. |
|
Product Width |
5.75 in. |
|
Product Weight (lbs) |
8.95 |
