This system is compatible with the S740RL-HO Sterilight Lamp and the QS-740 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for SP740-HO includes:
| Product Details | |
|---|---|
|
Ambient Temperature Range |
36-104 °F |
|
Features |
UV Intensity Monitor |
|
Frequency Rate |
50/60 Hz |
|
Inlet Connection |
3/4″ FPT 1″ MPT |
|
Max Pressure (Psi) |
125 |
|
Min Pressure (Psi) |
14.5 |
|
Outlet Connection |
3/4″ FPT 1″ MPT |
|
Power |
88 Watts |
|
Size |
3/4″ 1″ |
|
Connection Type |
Female (FPT) Male (MPT) |
|
Diameter |
3-1/2″ |
|
Flow Rate |
42 GPM (30mJ/cm2 Dose) |
|
Type |
Single UV System |
|
Voltage |
120 V |
| Warranty & Certifications | |
|
Warranty |
7 yr for chamber, 1 yr for lamps and probes, 5 yr pro rated on all other components |
| Product Weight & Dimensions | |
|
Power Supply Dimensions |
11″ x 4-1/2″ x 2″ |
|
Product Length |
39.4″ |
|
Product Weight (lbs) |
24 |
