This system is compatible with the S410RL-HO Sterilight Lamp and the QSO-410 Quartz Sleeve. For any necessary system replacements, the UV Lamp/Quartz Sleeve Combo Kit for VH410 includes:
NOTE: 230V systems are shipped with 2-prong continental European (CEE-7/7) 2 pin with ground “Schuko” power cord.
| Product Details | |
|---|---|
|
Ambient Temperature Range |
32-104 °F |
|
Body Material |
304 Stainless Steel |
|
Features |
Audible Lamp Failure Visual Power On Lamp Timer Flow Restrictor |
|
Frequency Rate |
50/60 Hz |
|
Inlet Connection |
3/4″ FPT 1″ MPT |
|
Max Pressure (Psi) |
125 |
|
Min Pressure (Psi) |
5 |
|
Outlet Connection |
3/4″ FPT 1″ MPT |
|
Power |
60 Watts |
|
Size |
3/4″ 1″ |
|
Connection Type |
Male (MPT) Female (FPT) |
|
Diameter |
3-1/2″ |
|
Flow Rate |
34 GPM (16mJ/cm2 Dose) 18 GPM (30mJ/cm2 Dose) 14 GPM (40mJ/cm2 Dose) |
|
Type |
Single UV System |
|
Voltage |
120 V |
| Shipping Dimensions | |
|
Shipping Length |
22.5 in. |
|
Shipping Width |
10.75 in. |
|
Shipping Height |
9.25 in. |
| Product Weight & Dimensions | |
|
Product Length |
23.5 in. |
|
Product Width |
3.5 in. |
|
Product Weight (lbs) |
17 |
| Product Details | |
|---|---|
|
Ambient Temperature Range |
32-104 °F |
|
Body Material |
304 Stainless Steel |
|
Features |
Audible Lamp Failure Visual Power On Lamp Timer Flow Restrictor |
|
Frequency Rate |
50/60 Hz |
|
Inlet Connection |
3/4″ FPT 1″ MPT |
|
Max Pressure (Psi) |
125 |
|
Min Pressure (Psi) |
5 |
|
Outlet Connection |
3/4″ FPT 1″ MPT |
|
Power |
60 Watts |
|
Size |
3/4″ 1″ |
|
Connection Type |
Male (MPT) Female (FPT) |
|
Diameter |
3-1/2″ |
|
Flow Rate |
34 GPM (16mJ/cm2 Dose) 18 GPM (30mJ/cm2 Dose) 14 GPM (40mJ/cm2 Dose) |
|
Type |
Single UV System |
|
Voltage |
120 V |
| Shipping Dimensions | |
|
Shipping Length |
30 in. |
|
Shipping Width |
10 in. |
|
Shipping Height |
11 in. |
| Product Weight & Dimensions | |
|
Product Length |
23.5 in. |
|
Product Width |
3.5 in. |
|
Product Weight (lbs) |
17 |
